Dehydration Tower

• CLIENTHANWHA IMPACT (2024)
• PROJECTNO.1 HPDT PROJECT
• LOCATIONKOREA
• MATERIALSA516-70N+SB265-1 CLAD
• SIZE (mm)43+Min.2 (T) x 5,200 (ID) x 57,160 (L) / 53,812 (L without skirt), Tray 64 Layers
• WEIGHT (set)394.2 tons

Vacuum Column

• CLIENTORPIC (2015)
• PROJECTSOHAR REFINERY IMPROVEMENT
• LOCATIONOMAN
• MATERIALSA204-AN+SA240-316L CLAD
• SIZE (mm)31+3 (T) x 10,000 (ID) x 43,750 (L)
• WEIGHT (set) 439 tons

Drying Column (Zirconium)

• CLIENTLOTTE BP CHEMICALS (2019)
• PROJECTACETIC ACID PLANT
• LOCATIONKOREA
• MATERIALB551-R60702
• SIZE (mm)10 (T) x 1,115 / 1,600 (ID) x 39,900 (L)
• WEIGHT (set)17 tons

Propylene Rectifier

• CLIENTKPIC (2016)
• PROJECTKPIC ONE
• LOCATIONKOREA
• MATERIALA516-70N
• SIZE (mm)39 (T) x 4,800 (ID) x 87,510 (L) (Supplied with Insulation and Tray)
• WEIGHT (set)715.9 tons

Propylene Fraction No.3

• CLIENTSAMSUNG TOTAL (2013)
• PROJECTPROPYLENE
• LOCATIONKOREA
• MATERIALA516-70N
• SIZE (mm)60+1.5 (T) x 4,100 (ID) x 98,600 (L) / 86,600 (L without skirt), Tray 180 layers
• WEIGHT (set)776.7 tons
